Let’s Build a Hatch Motor Boat!

Let’s Build a Hatch Motor Boat!





Before you launch, the guides have to rig their rafts





The Grand Canyon is home to many different types of whitewater rafts, but the biggest and most memorable boats on the river are the motor rigs. The two types of motor rigs you’ll see or ride on when on a Grand Canyon rafting trip are the S-rig and the J-rig. At Hatch we use S-rigs, so let’s rig one for a trip.



Rubber motor boat pontoons for river rafting in Grand Canyon sit in the Hatch River Expeditions warehouse waiting for off-season maintenance.

One part of winter work is to sand off the top layer of rubber and then apply a fresh coat for the next river season.



These boats are kind of like lego sets. They can be completely taken apart and rebuilt with mixed and matched pieces. In fact these boats are completely customizable and every company has their own version. Just like when you build a lego set, we are going to start with the base of the boat.



The Base

The base of an S-rig is made of a narrow, oval-shaped rubber pontoon (we’ll get to the side tubes later). These pontoons were not always used for whitewater rafting – originally, they had an entirely different purpose! During World War II these pontoons were lashed together to create a temporary floating bridge for tanks to cross rivers; what are now the front and back of the raft were originally the sides of a bridge. In fact, the Colorado River near Yuma, AZ, was a testing ground for the then-new rubber design. After the war the US no longer had use for them, so they sold them for cheap in military surplus stores. That’s where river runners saw them and got the crazy idea to turn them into whitewater rafts. Georgie White was one of the trailblazers for this repurposed use beginning in 1953.



Motor boat frames sit in the warehouse

The metal frame for a motorized S-rig raft. This sits between the long sides of a oval pontoon and makes up the “tea room.”





The Frames

The next step in building an S-rig is the frames. These metal frames fit perfectly into the center of the oval with wings that extend across the tops of both sides of the pontoon. The frame at the front of the boat is called the duffel frame and the frame at the back of the boat is called the motor frame. These frames are then secured to the pontoon with heavy duty straps that wrap around the pontoon and connect back to the frame. Just like everything else on the boat, these straps are also custom. The Hatch family themselves make the straps for every boat.



Storage Boxes

Once the frames are strapped down it’s time to add all the storage boxes, coolers, and everything else we need to have a successful trip. To make this easier let’s look at a diagram of the setup.



Labeled pieces of a Hatch Motor Boat



From back to front:

View of swamper box, first aid and motor box on motorized river rafting S-rig.

A swamper box, first aid kit ammo can, and motor box on a motorized S-rig ready for a Grand Canyon adventure.

  1. The Motor: The motor is one of the last things we load, but it’s at the rear of the boat. The motor is  placed in the space between the motor frame and the pontoon called the motor well.
  2. Guide and Swamper Boxes: These boxes hold all sorts of gear that the guide or swamper might need access to throughout the day. You might also hear them called toy boxes by the guides.
  3. Motor Box: This large box holds – you guessed it – our spare motor. It also holds a few other spare parts we need on our trip. On the outside of the box hangs a strap with pockets called a schnadle cradle. Schandle is just another word for stuff, which is exactly what this holds. From tools and duct tape to soap and sunscreen, it’s got all your guides essentials. You never know what you’ll find in it!
  4. Generator Box: This box sits right next to the guide box and holds our generator, battery, radio and many more just-in-case supplies we may need throughout the trip.
  5. First Aid Kit: Next to the swamper box sits an ammo can with a red lid, this is our extensive first aid kit.
  6. Produce Cooler: This big metal box is placed on the bottom on the motor frame and becomes the floor of the tea room (more on that later). This box is full of ice and all the produce needed for the whole trip.
  7. Dairy Up Cooler: This white igloo cooler sits right on top of the produce cooler and holds all the dairy items that we need to easily access. It’s called the dairy up cooler because it is not buried by other gear during the day.
  8. Food Boxes: On each boat there are four food boxes each containing food for various meals and snacks.
  9. Weenie Tube: In between the motor and duffel frames is a short rubber tube which prevents the two frames from hitting each other when the boat flexes, especially when going through rapids.



Duffel Frame

Next let’s look at the duffel frame. Everything listed below is hidden from view during the day by the duffel pile that sits on top of it (these are the blue numbers in the diagram above).

  1. Meat, Dairy Down, and Ice Cooler: In the floor of each duffel frame there are three coolers like the dairy up cooler. One is for the meat we eat throughout the trip, another for more dairy, and the last is just for ice to replenish the other coolers throughout the trip. This lower section sits in the water, which help to keep cold things cold for longer in the hot desert.
  2. Hatches: No, not a mini family of Hatches! Less exciting but still important, there are two hatches built into the front of each duffel frame. One for all our kitchen equipment (stove, pots, pans, coffee pots, etc.) and the other for miscellaneous equipment that we need or couldn’t fit in the kitchen hatch.



Load It Up…

Everything we have done to build and load the boat has been at the warehouse, so now it’s time to take it to the river! The entire rig is hauled down on custom 35′ trailers with rollers. Once the boat is off the trailer and in the water we put on the side tubes. These are long, straight, rubber pontoons that curve upward at the front end. The side tubes are strapped onto the oval pontoon on both sides of the boat. Side tubes make the boat more stable in the rapids and have the added benefit of making it easier for people to stay on the boat. You still need to hold on though!

Once all our stuff is on the boat, it’s time to load all your stuff! Once all your drinks are labeled and your dry bags packed, we load them all on the boat. All your gear will sit on the duffel frame on top of the coolers and hatches. The pile is then covered by a waterproof tarp and strapped down to the boat.



… And Launch!

Guests loading up motor boat



Now the moment you’ve all been waiting for: it’s time for you to get on the boat!

Just like everything else on the boat, you too have a designated spot. Don’t worry, there’s no seating chart, but there are places you can and can’t sit.

Starting at the back of the boat is the motor room. This is where your boatman will be, and your swamper most of the time when they aren’t moving around on the boat. This is behind the motor box. In front of the motor box is the tea room where you can sit on top of the food boxes with your legs towards the inside of the boat. This is the driest place to ride in the boat – you’ll still get wet but maybe not drenched. Next is the boards or the gutter. Alongside both sides of the duffel pile are padded metal boards where you sit with your back against the duffel pile and your feet can rest on the side tubes. These spots can be a splashy ride, but you get a backrest! And finally the best, wettest place to ride on the boat: the bathtub. This is the very front of the boat. Similar to the gutter there is a board that sits across the front of the boat along the duffel pile. Here you are facing all the whitewater action head on! It’s by far the most exciting place to ride – as long as you don’t mind getting soaked! In the heat of summer, that can feel pretty nice though. There are handles in lots of places for the rapids, but on flat water you can choose to sit down and relax or stand up so you can a 360° experience.

Now that the boat is all loaded up it’s time to do a river trip!
